lxt-352s
lianxing computerized flat knitting machines are used digital technology to achieve the patterns of transfer, tuck, pointel, intarsia, jacquard, apparent shape, hidden shape and other regular pattern knitting functions, can knit basic single or double jersey plain fabric, irregular multi-colors jacquard, intarsia, cable and pointel structure patterns.
brand gauge | lianxing 5g,7g,8g,10g,12g,14g,16g and multi-gauge6.2g ,3-5-7g; |
knitting width | 52"，weight:about 1080~ 1180kgm |
knitting speed | controlled by ac servo motor with 24 sections speed optional, max 1.2m/s; |
knitting system | ge2:single carriage with three systems; |
knitting function | knit, miss, tuck, transfer, pointelle, intarsia, jacquard, hide,or apparent shaping and other regular patterns. |
racking system | controlled by ac servo motor racking within 2 inches and with fine micro adjustable function. |
encoder | advanced encoder adopted. |
transfer cam | combined type transfer cam, both single and double system all can transfer separately or synchronously, also can transfer by one system, knitting by another, which will achieve high efficiency. |
stitch density
| controlled by stepping motor,24 sections density selectable,adjustable scope supported by subdivision technology:0-650,the length of knitwear piece can be accurately controlled. |
sinker system | controlled by stepping motor, adjustable to different knitwear ,achieve various results of narrowing and widening. |
comb and culter(c series) | adopting close_end u-shaped composite needles which can hold and release yarns on the principle that release freely. |
clip and cutter(c series) | including 4 clips and 2 cutters,controlled by 6 motors separately.program command can proceed simultaneously or separately to further increase efficiency and reducewaste of yarn. |
take down roller | computerized, controlled by stepping motor,24 levels selection of tension with adjustable scope:0-100. |
yarn feeder | 2x8 yarn feeders on both sides of 1 guide rail of 4, switchover on any position of needle bed (special intarsia yarn feeders optional). |
protection system | the machine will automatically alarm if yarn-breaking, knots floating, rewind, end of knitting, fail of racking, needle jack crash, error programming occur, also with safety auto-lock protection device. |
control system | 1,lcd touch screen, graphical interface. usb and network compatible, with expanded memory of up to 1g. a great amount of patterns can be stored and mobilized for use at any time as per production requirements. 2,monitoring display: various operating parameters can be displayed and can be adjusted anytime when the machine is running, making operations as convenient and time-saving as possible. 3,design system and control system (softwares) are easy to update for free. 4,multi-language operating system:there are chinese, english and arabic versions. languages can be switched according to customer requirements. |
power | single-phase 220v/50hz,1.5kw,adopt advanced cmos technology enabling memorizing at the instant of power outages and restoring of knitting thereafter. |
